This is the challenge: possible to improve the gearbox in which Malossi gears run, super performing and above all more beautiful?

Die-cast aluminum, machined and finished in our lines. It looks like a crankcase but it is not: it is a work of art. The art of ennobling every single part of one of our favorite vehicles, the Ciao (this gearbox fits Piaggio mopeds like Ciao, Si and range cousins). The art of increasing performance by shaping matter within the limits imposed by physics and factory encumbrances.


What's new.

We added ribs to strategic sections to increase stiffness. We increased the diameter of the wheel shaft bearing seat and all others, and added ribs to compensate for the increased performance.
All within the original space: the gearbox uses pressed needle bearings for all the gearbox shafts, NBR oil seals with a spring lip and auxiliary lip, and a labyrinth to trap oil while allowing the gearbox to "breathe."

What we optimized.

The gearbox simplifies gear housing, improves the operation of the brake shoe with dedicated machined surfaces to guide it more accurately. Two concentric positioning bushings enclosed by five screws (one more than the original), with hexagonal cylindrical heads. The gearbox uses high-quality steel pins, pressed into the housing, for the lever and brake shoe pivots. To improve rigidity we have eliminated the gasket: everything is sealed with silicone paste as in the most modern vehicles (perfect is LOCTITE® SI 5926 that you can find in our catalog).
The screws for attachment to the swingarm are now through-bolted and doubled in length, with special sealant applied to the threads, so as to ensure a top fastening. The gearbox comes complete with bearings, oil seals, screws and washers: everything you need for a perfect fit with Malossi gears (but if you want you can also fit it with the original gears).


WARNING: the gearbox does not allow the vehicle to operate in "bicycle" mode.


Technical characteristics

Couple Carter, die-cast aluminum alloy silicon material with high mechanical strength.
High-strength textured black paint surface treatment.
Crankcases complete with locking and fastening screws, washers, roller cases and pins for lever and brake strain.
Completely redesigned with reinforced structure with added ribs to withstand increased stresses.
Oil breather with internal labyrinth and external fitting.
Crankcase coupling guaranteed by 5 fixing screws and 2 bushings.
Vehicle hub fixing screws M10 x 18.
Wheel axle inner bearing 15 x 21 x 12.
Wheel axle output bearing 20 x 26 x 12.
Clutch shaft inner bearing 9 x 13 x 12.
Clutch shaft output bearing 13 x 19 x 12.
4 gear transmission bearings 9 x 13 x 12.
FKM oil seals.
Pan head screw with bronze sealing washer for oil level/filling.
